12-13
12-2 Parameter List
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
12
Appendix
Note 1: The default setting is 11 for 200-V Servo Drives of 1 kW or higher and 400-V Servo Drives.
Note 2: The default setting is 0 for 100-V Servo Drives of 400 W, 200-V Servo Drives of 750 W to
5 kW, and 400-V Servo Drives of 5 kW or lower.
016
Regeneration
Resistor
Selection
Select the Regeneration Resistor used.
See
Note 2
− 0 to 3 Yes
0
Use the Built-in Resistor.
Triggering of regeneration overload
protection (Alarm No. 18) depends on
the Built-in Resistor (with approx. 1%
duty).
1
Use an External Resistor.
The regeneration processing circuit
operates and regeneration overload
protection (Alarm No. 18) is triggered
when the operating rate of the
Regeneration Resistor exceeds 10%.
2
Use an External Resistor.
Regeneration overload protection
(Alarm No. 18) does not operate.
3
No Regeneration Resistor
All regeneration power is processed
with built-in capacitors.
017
External
Regeneration
Resistor Setting
Select the type of load ratio calculation for
the External Regeneration Resistor.
0 − 0 to 4 Yes
0
Regeneration load ratio is 100% when
operating rate of the External
Regeneration Resistor is 10%.
1Reserved
2Reserved
3Reserved
4Reserved
Pn number
Parameter
name
Description
Default
setting
Unit
Setting
range
Power
supply
OFF to
ON
To Next Page
