Omron OMNUC G5 R88D-KT50F User Manual

2-27
2-4 External and Mounting Dimensions
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
Single-phase/3-phase 100 VAC: R88D-KT02L (200 W)
Single-phase/3-phase 200 VAC: R88D-KT04H (400 W)
Wall Mounting
External dimensions Mounting dimensions
Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
* Rectangular hole dimensions are reference values.
55
150
130
150
43
6
55
140
70
2-M4
Rectangular
hole
55
47
7
φ5.2
180 170 150
7
5.2
R2.6
2.5
130
19.5
2.5
8
170
70
2-M4
(57)*
6
(158)*
