2-30
2-4 External and Mounting Dimensions
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
3-phase 200 VAC: R88D-KT20H (2 kW)
Wall Mounting
External dimensions
Mounting dimensions
86
85
5017.5
42.5
5.2
5.2
φ5.2
R2.6 R2.6
198
188
168
17.5
50
5.25.2
42.5
φ5.2
R2.6
R2.6
193.5
3.5
70
25
188
168
86
50
18.5
6-M4
