Standards Compliance
5
5.2 European Standards
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 177
Model Terminals
Recommended
Gauge
mm
2
Applicable Gauge
(IP20 Applicable
Gauge
*1
)
mm
2
Wire
Stripping
Length
*2
mm
Terminal Screw
Tightening Torque
N∙m (lb.∙in.)
Size Shape
4103
R/L1, S/L2, T/L3 35
16 - 50
(50)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
U/T1, V/T2, W/T3 35
16 - 50
(50)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
-, +1 50
25 - 70
(50 - 70)
27 M8
Hex socket cap
(WAF: 6 mm)
10 - 12
(89 - 107)
B1, B2 25
6 - 35
(6 - 35)
21 M6 Minus (-)
3 - 3.5
(27 - 31)
16
16 - 25
(-)
- M6 Hex bolt (+)
5.4 - 6.0
(47.8 - 53.1)
4140
R/L1, S/L2, T/L3 50
50 - 95
(95)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
U/T1, V/T2, W/T3 50
50 - 95
(95)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
-, -, +1, +1
*5
25
16 - 50
(50)
28 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
B1, B2
*6
50
25 - 70
(50 - 70)
28 M8
Hex socket cap
(WAF: 6 mm)
8 - 9
(71 - 80)
25
25 - 50
(-)
- M8 Hex bolt (slotted)
9.0 - 11
(79.7 - 97.4)
4168
R/L1, S/L2, T/L3 70
50 - 95
(95)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
U/T1, V/T2, W/T3 70
50 - 95
(95)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
-, -, +1, +1
*5
35
16 - 50
(50)
28 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
B1, B2
*6
50
25 - 70
(50 - 70)
28 M8
Hex socket cap
(WAF: 6 mm)
8 - 9
(71 - 80)
35
25 - 50
(-)
- M8 Hex bolt (slotted)
9.0 - 11
(79.7 - 97.4)
4208
R/L1, S/L2, T/L3 50 × 2P
25 - 95 × 2P
(70 - 95 × 2P)
- M10 Hex self-locking nut
20
(177)
U/T1, V/T2, W/T3 50 × 2P
25 - 95 × 2P
(70 - 95 × 2P)
- M10 Hex self-locking nut
20
(177)
-, +1 70 × 2P
35 - 120 × 2P
(120 × 2P)
- M10 Hex self-locking nut
20
(177)
+3 35 × 2P
25 - 70 × 2P
(70 × 2P)
- M10 Hex self-locking nut
20
(177)
50
50 - 240
(-)
- M10 Hex bolt (slotted)
18 - 23
(159 - 204)
4250
R/L1, S/L2, T/L3 50 × 2P
25 - 95 × 2P
(70 - 95 × 2P)
- M10 Hex self-locking nut
20
(177)
U/T1, V/T2, W/T3 50 × 2P
25 - 95 × 2P
(70 - 95 × 2P)
- M10 Hex self-locking nut
20
(177)
-, +1 70 × 2P
35 - 120 × 2P
(120 × 2P)
- M10 Hex self-locking nut
20
(177)
+3 50 × 2P
25 - 70 × 2P
(70 × 2P)
- M10 Hex self-locking nut
20
(177)
70
70 - 240
(-)
- M10 Hex bolt (slotted)
18 - 23
(159 - 204)
