11.4 C: TUNING
410 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
◆ C6: DUTY AND CARRIER
No.
(Hex.)
Name Description
Default
(Range)
Ref.
C6-01
(0223)
ND/HD Duty Selection
Sets the drive duty rating.
0 : HD Rating
1 : ND Rating
0
(0, 1)
584
C6-02
(0224)
Carrier Frequency
Selection
Sets the carrier frequency for the transistors in the drive.
1 : 2.0 kHz
2 : 5.0 kHz (4.0 kHz for AOLV/PM)
3 : 8.0 kHz (6.0 kHz for AOLV/PM)
4 : 10.0 kHz (8.0 kHz for AOLV/PM)
5 : 12.5 kHz (10.0 kHz for AOLV/PM)
6 : 15.0 kHz (12.0 kHz AOLV/PM)
7 : Swing PWM 1 (Audible Sound 1)
8 : Swing PWM 2 (Audible Sound 2)
9 : Swing PWM 3 (Audible Sound 3)
A : Swing PWM 4 (Audible Sound 4)
F : User (C6-03 to C6-05)
Note:
The carrier frequency for Swing PWM 1 to 4 is equivalent to 2.0 kHz.
Determined by A1-02,
C6-01, and o2-04
(Determined by A1-02)
585
C6-03
(0225)
Carrier Upper Frequency
Limit
Sets the upper limit of the carrier frequency. Set C6-02 = F [Carrier Frequency
Selection = User (C6-03 to C6-05)] to set this parameter.
Determined by C6-02
(1.0 - 15.0 kHz)
586
C6-04
(0226)
Carrier Lower Frequency
Limit
Sets the lower limit of the carrier frequency. Set C6-02 = F [Carrier Frequency
Selection = User Defined (C6-03 to C6-05)] to set this parameter.
Determined by C6-02
(1.0 - 15.0 kHz)
586
C6-05
(0227)
Carrier Freq Proportional
Gain
Sets the proportional gain for the carrier frequency. Set C6-02 = F [Carrier Frequency
Selection = User Defined (C6-03 to C6-05)] to set this parameter.
Determined by C6-02
(0 - 99)
587
C6-09
(022B)
Carrier@Autotune
Rotational
Sets the Auto-Tuning carrier frequency. Usually it is not necessary to change this
setting.
0 : 5 kHz
1 : use C6-03
0
(0, 1)
587
