11.5 d: REFERENCE
414 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d5-04
(029D)
Speed Limit
Sets the speed limit during Torque Control as a percentage of E1-04 [Max Output
Frequency]. Set d5-03 = 2 [Speed Limit Selection = d5-04 Setting] before you set this
parameter.
0%
(-120 - +120%)
606
d5-05
(029E)
Speed Limit Bias
Sets a bias to the speed limit as a percentage of E1-04 [Max Output Frequency].
10%
(0 - 120%)
606
d5-06
(029F)
Spd/Trq Chg Time
Sets the delay time to switch between Speed Control and Torque Control. Set H1-xx =
13 [H1-xx: MFDI Function Select = Spd/Trq Switch] before you set this parameter.
0 ms
(0 - 1000 ms)
606
d5-08
(02B5)
UniDir Speed Bias
Sets the direction of the speed limit reference to which Speed Limit Bias [d5-05]
applies.
0 : Disabled
1 : Enabled
1
(0, 1)
606
◆ d6: FIELD WEAKENING / FORCING
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d6-01
(02A0)
Field Weak Level
Sets the drive output voltage as a percentage of E1-05 [Max Output Voltage] when H1-
xx = 44 [Field Weakening] is activated.
80%
(0 - 100%)
607
d6-02
(02A1)
Field Weak FqLimit
Sets the minimum output frequency to start field weakening.
0.0 Hz
(0.0 - 590.0 Hz)
607
d6-03
(02A2)
Field Force Selection
Sets the field forcing function.
0 : Disabled
1 : Enabled
0
(0, 1)
607
d6-06
(02A5)
Field Force Limit
Sets the maximum level that Field Forcing can increase the excitation current reference
as a percentage of E2-03 [Mot No-Load Current]. Usually it is not necessary to change
this setting.
400%
(100 - 400%)
607
◆ d7: OFFSET FREQUENCY
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d7-01
(02B2)
RUN
Offset Frq 1
Sets the value to add to or subtract from the frequency reference when H1-xx = 0E [H1-
xx: MFDI Function Select = Offset Frq 1] as a percentage of E1-04 [Max Output
Frequency].
0.0%
(-100.0 - +100.0%)
608
d7-02
(02B3)
RUN
Offset Frq 2
Sets the value to add to or subtract from the frequency reference when H1-xx = 0F [H1-
xx: MFDI Function Select = Offset Frq 2] as a percentage of E1-04 [Max Output
Frequency].
0.0%
(-100.0 - +100.0%)
608
d7-03
(02B4)
RUN
Offset Frq 3
Sets the value to add to or subtract from the frequency reference when H1-xx = 10 [H1-
xx: MFDI Function Select = Offset Frq 3] as a percentage of E1-04 [Max Output
Frequency].
0.0%
(-100.0 - +100.0%)
608
