11.8 H: TERMINALS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 435
Setting Function Description Ref.
7F Comms Test
Set the function for the drive to self-test RS-485 serial communications operation.
687
90 to 97 Q2pack DI1 to 8
Sets digital inputs used with Q2pack. Refer to the Q2pack Online Manual for more information.
687
9F Q2pack Disable
Sets operation of the Q2pack program saved in the drive.
ON : Disabled
OFF : Enabled
Note:
Set A1-07 = 2 [Q2pack Enable = With DI] to use this function.
687
101 to 19F Inverse Input of 1 to 9F Sets the function of the selected MFDI to operate inversely. To select the function, enter “1xx”, where the “xx” is
the function setting value.
Note:
You cannot use inverse input for all functions. Refer to Table 12.40 for more information.
688
◆ H2: DIGITAL OUTPUTS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H2-01
(040B)
2NO-2CM Func
Selection
Sets the function for MFDO terminal 2NO-2CM.
Note:
Set this parameter to 0 when the terminal is not being used or to use the terminal in
through mode.
0
(0 - 1FF)
690
H2-02
(040C)
3NO-3CM Func
Selection
Sets the function for MFDO terminal 3NO-3CM.
Note:
Set this parameter to 0 when the terminal is not being used or to use the terminal in
through mode.
1
(0 - 1FF)
690
H2-03
(040D)
4NO-4CM Funct
Selection
Sets the function for MFDO terminal 4NO-4CM.
Note:
Set this parameter to 0 when the terminal is not being used or to use the terminal in
through mode.
2
(0 - 1FF)
690
H2-06
(0437)
kWH Out Unit Selection
Sets the unit for the output signal when H2-01 to H2-03 = 65 [xNO-xCM Func
Selection = WattH Pulse].
1 : 0.1 kWh units
2 : 1 kWh units
3 : 10 kWh units
4 : 100 kWh units
5 : 1000 kWh units
1
(1 - 5)
690
H2-07
(0B3A)
Mbus Reg1 Address
Select
Sets the address of the Modbus register output to the MFDO terminal.
0001
(0001 - 1FFF)
691
H2-08
(0B3B)
Mbus Reg1 Bit Select
Sets the bit of the Modbus register output to the MFDO terminal.
0000
(0000 - FFFF)
691
H2-09
(0B3C)
Mbus Reg2 Address
Select
Sets the address of the Modbus register output to the MFDO terminal.
0001
(0001 - 1FFF)
691
H2-10
(0B3D)
Mbus Reg2 Bit Select
Sets the bit of the Modbus register output to the MFDO terminal.
0000
(0000 - FFFF)
691
H2-20
(1540)
Compare1 Mon.
Selection
Sets the monitor number for comparator 1. Set the x-xx part of the Ux-xx [MONITOR].
For example, set x-xx to 102 to monitor U1-02 [Output Frequency].
102
(000 - 999)
692
H2-21
(1541)
Compare1 Low Limit
Sets the lower limit detection level for comparator 1 when the full scale analog output
for the monitor selected in H2-20 [Compare1 Mon.Selection] is the 100% value.
0.0%
(0.0 - 300.0%)
692
H2-22
(1542)
Compare1 Up Limit
Sets the upper limit detection level for comparator 1 when the full scale analog output
for the monitor selected in H2-20 [Compare1 Mon.Selection] is the 100% value.
0.0%
(0.0 - 300.0%)
692
H2-23
(1543)
Compare1 Hysteresis
Sets the hysteresis level for comparator 1 when the full scale analog output for the
monitor selected in H2-20 [Compare1 Mon.Selection] is the 100% value.
0.0%
(0.0 - 10.0%)
692
H2-24
(1544)
Compare1 On-Delay
Time
Sets the on-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
692
