11.8 H: TERMINALS
434 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Setting Function Description Ref.
63 Down Command
Sets the command to decrease the drive frequency reference using a button. Users must also set Setting 62 [Up
Command].
ON : Decreases the frequency reference.
OFF : Holds the current frequency reference.
683
65 Up2 Command
Sets the function to increase the frequency reference bias value to accelerate the motor when the terminal is
activated. Set this function and H1-xx = 66 [Dw2 Command] together.
Note:
When using this function, set the optimal bias limit value with d4-08 and d4-09 [Up/Dw2 Bias Upper Limit
and Up/Dw2 Bias Lower Limit].
684
66 Dw2 Command
Sets the function to increase the frequency reference bias value to accelerate the motor when the terminal is
activated. Set this function and H1-xx = 65 [Up2 Command] together.
Note:
When using this function, set the optimal bias limit value with d4-08 and d4-09 [Up/Dw2 Bias Upper Limit
and Up/Dw2 Bias Lower Limit].
685
67 SpeedSearch Fmax
Sets the function to start speed search using an external reference although b3-01 = 0 [SpSrch@Start Selection =
Disabled].
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 67 and 68 are set at the same
time.
685
68 SpeedSearch Fref
Sets the function to start speed search using an external reference although b3-01 = 0 [SpSrch@Start Selection =
Disabled].
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 67 and 68 are set at the same
time.
685
6A PID Disable
Sets the command to disable PID control when b5-01 = 1 [PID Enable = Enabled].
ON : PID control disabled
OFF : PID control enabled
685
71 PID I Reset
Sets the command to reset and hold the PID control integral to 0 when the terminal is ON.
686
72 PID I Hold
Sets the command to hold the integral value of the PID control while the terminal is activated.
686
75 PID SS Cancel
Sets the PID soft starter function.
ON : Disabled
OFF : Enabled
686
76 PID InLv Select
Sets the command to turn the terminal ON and OFF to switch the PID input level (polarity).
686
77 PID SP 1
Set this function and H1-xx = 78 [PID SP 2] together. Sets the function to switch the PID setpoint to b5-58 to b5-
60 [PID Setpoint 2 to PID Setpoint 4].
686
78 PID SP 2
Set this function and H1-xx = 77 [PID SP 1] together. Sets the function to switch the PID setpoint to b5-58 to b5-
60 [PID Setpoint 2 to PID Setpoint 4].
686
7A PID BiDir
Sets operation of the PID Bi-Directional function.
ON : Enabled
OFF : Disabled
686
7B Fault Reset
Sets the command to reset the current fault when the Run command is inactive.
Note:
The drive ignores the fault reset command when the Run command is active. Remove the Run command
before trying to reset a fault.
687
7C Prg Lock
Sets the command to prevent parameter changes when the terminal is OFF.
ON : Program Lockout
OFF : Parameter Write Prohibit
687
7D Drive OH2
Sets the drive to display an oH2 [Drive Overheat Warning] alarm when the input terminal is ON. The alarm does
not have an effect on drive operation.
687
7E Node Setup
Sets the function in CANopen communications to start the Node Setup function to set the drive node address from
the host controller.
687
