11.8 H: TERMINALS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 433
Setting Function Description Ref.
32 HiSlipBraking
Sets the command to use high-slip braking to stop the motor.
678
34 Fast Stop NO
Sets the command to ramp to stop in the deceleration time set in C1-09 [Fast Stop Time] when the input terminal is
ON while the drive is operating.
678
35 Fast Stop NC
Sets the command to ramp to stop in the deceleration time set in C1-09 [Fast Stop Time] when the input terminal is
ON while the drive is operating.
678
3E SCBraking NO
Sets operation of Short Circuit Braking (N.O.).
ON : Short Circuit Braking is enabled.
OFF : Normal operation
Note:
When A1-02 = 8 [Control Method = EZ Vector], this function is available if you use a PM motor.
679
3F SCBraking NC
Sets operation of Short Circuit Braking (N.C.).
ON : Normal operation
OFF : Short Circuit Braking is enabled.
Note:
When A1-02 = 8 [Control Method = EZ Vector], this function is available if you use a PM motor.
679
40 KEB Thru1 NC
Sets operation of the KEB1 function through the KEB Ride-Thru 1 (N.C.).
ON : Normal operation
OFF : Deceleration during momentary power loss
679
41 KEB Thru1 NO
Sets operation of the KEB1 function through the KEB Ride-Thru 1 (N.O.).
ON : Deceleration during momentary power loss
OFF : Normal operation
679
42 KEB Thru2 NC
Sets operation of the KEB2 function through the KEB Ride-Thru 2 (N.C.).
ON : Normal operation
OFF : Deceleration during momentary power loss
680
43 KEB Thru2 NO
Sets operation of the KEB2 function through the KEB Ride-Thru 2 (N.O.).
ON : Deceleration during momentary power loss
OFF : Normal operation
680
44 Field weakening
Sets the function to send the Field Weakening Level and Field Weakening Frequency Limit commands set in d6-01
[Field Weak Level] and d6-02 [Field Weak FqLimit] when the input terminal is activated.
680
45 ASR Gain Switch
Sets the function to switch the ASR proportional gain set in C5-01 [ASR PGain 1] and C5-03 [ASR PGain 2].
ON : C5-03
OFF : C5-01
680
46 ASR I Reset
Sets the command to reset the integral value and use PI control or P control for the speed control loop.
ON : P control
OFF : PI control
681
47 PG Enc Disable
Sets the command to disable speed feedback control and run the drive in V/f control or use speed feedback from
the encoder.
ON : Speed feedback control disable (V/f Control)
OFF : Speed feedback control enable (Closed Loop V/f Control)
681
60 Timer Fn Input
Sets the command to start the timer function. Use this setting with Timer Output [H2-xx = 39].
681
61 Motor 2 Select
Sets the command for the drive to operate motor 1 or motor 2. Stop the motors before switching.
ON : Operate motor 2
OFF : Operate motor 1
681
62 Up Command
Sets the command to use a button to increase the drive frequency reference. You must also set Setting 63 [Down
Command].
ON : Increases the frequency reference.
OFF : Holds the current frequency reference.
682
