12.7 H: TERMINALS
692 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
■ H2-20 Compare1 Mon.Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-20
(1540)
Compare1 Mon.Selection
Sets the monitor number for comparator 1. Set the x-xx part of the Ux-xx [MONITOR]. For
example, set x-xx to 102 to monitor U1-02 [Output Frequency].
102
(000 - 999)
Note:
• The configurable monitor changes when the control method changes.
• To use in through mode, set this parameter to 000 or 031. You can set the terminal output level from the PLC through Modbus
communications or the communication option.
• Refer to H2-xx = 3C and 3D [MFDO Function Select = Comparator 1 and Comparator 1] for more information about the comparator
function.
■ H2-21 Compare1 Low Limit
No.
(Hex.)
Name Description
Default
(Range)
H2-21
(1541)
Compare1 Low Limit
Sets the lower limit detection level for comparator 1 when the full scale analog output for the
monitor selected in H2-20 [Compare1 Mon.Selection] is the 100% value.
0.0%
(0.0 - 300.0%)
Note:
Refer to H2-xx = 3C and 3D [MFDO Function Select = Comparator 1 and Comparator 2] for more information about the comparator
function.
■ H2-22 Compare1 Up Limit
No.
(Hex.)
Name Description
Default
(Range)
H2-22
(1542)
Compare1 Up Limit
Sets the upper limit detection level for comparator 1 when the full scale analog output for the
monitor selected in H2-20 [Compare1 Mon.Selection] is the 100% value.
0.0%
(0.0 - 300.0%)
Note:
Refer to H2-xx = 3C and 3D [MFDO Function Select = Comparator 1 and Comparator 2] for more information about the comparator
function.
■ H2-23 Compare1 Hysteresis
No.
(Hex.)
Name Description
Default
(Range)
H2-23
(1543)
Compare1 Hysteresis
Sets the hysteresis level for comparator 1 when the full scale analog output for the monitor
selected in H2-20 [Compare1 Mon.Selection] is the 100% value.
0.0%
(0.0 - 10.0%)
Note:
Refer to H2-xx = 66 and 67 [MFDO Function Select = Comparator1 and Comparator2] for more information about the comparator
function.
■ H2-24 Compare1 On-Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-24
(1544)
Compare1 On-Delay Time
Sets the on-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
Note:
Refer to H2-xx = 66 and 67 [MFDO Function Select = Comparator1 and Comparator2] for more information about the comparator
function.
■ H2-25 Compare1 Off-Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-25
(1545)
Compare1 Off-Delay Time
Sets the off-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
