Omron Q2A Series Technical Manual

Receiving
1
1.1 Model Number and Nameplate Check
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 21
Table 1.1 Model Number Details
No. Description
1 Q2 Series
2 A Series
3 IP Protection Class
• A: IP20
4 Input Power Supply Voltage
• 4: Three-Phase AC 400 V Class
5 Rated Output Current
Note:
Refer to the rated output current list for more information.
6
Specification
• A: Standard
7 Coating Specification
• A: Standard
8 Version
■ Rated Output Current
These output current values are applicable for drives that operate at standard specifications.
• These output current values are applicable for drives that operate at standard specifications.
• Derate the current in applications that:
– Increase the carrier frequency
– Have high ambient temperature
– Install drives side-by-side.
• Use C6-01 [ND/HD Duty Selection] to select Normal Duty rating (ND) or Heavy Duty rating (HD).
Table 1.2 Three-Phase AC 400 V Class (Input Voltage < 460 V)
Model
E1-01 [Input AC Supply Voltage] < 460
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable Motor
Output
kW
Rated Output Current
A
Maximum Applicable Motor
Output
kW
Rated Output Current
A
4002 0.55
1.8
0.75
2.1
4004 1.1
3.4
1.5
4.1
4005 1.5
4.8
2.2
5.4
4007 2.2
5.5
3.0
7.1
4009 3.0
7.2
4.0
8.9
4012 4.0
9.2
5.5
11.9
4018 5.5
14.8
7.5
17.5
4023 7.5
18
11
23.4
4031 11
24
15
31
4038 15
31
18.5
38
4044 18.5
39
22
44
4060 22
45
30
59.6
4075 30
60
37
74.9
4089 37
75
45
89.2
4103 45
91
55
103
4140 55
112
75
140
4168 75
150
90
168
4208 90
180
110
208
4250 110
216
132
250
