Omron Q2A Series Technical Manual

6.2 Modbus Communications
230 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Register No.
(Hex.)
Description
002B
U1-10 [In Terminal Status]
bit 0 1: Control circuit terminal DI1 ON
bit 1 1: Control circuit terminal DI2 ON
bit 2 1: Control circuit terminal DI3 ON
bit 3 1: Control circuit terminal DI4 ON
bit 4 1: Control circuit terminal DI5 ON
bit 5 1: Control circuit terminal DI6 ON
bit 6 1: Control circuit terminal DI7 ON
bit 7 1: Control circuit terminal DI8 ON
bit 8 - F Reserved
002C
Drive Status 2
bit 0
During Run
1: During run
bit 1
During zero speed
1: During zero speed
bit 2
Speed agreement
1: During agreement
bit 3
User-defined speed agreement
1: During agreement
bit 4
Frequency Detection 1
1: Output frequency ≤ L4-01
bit 5
Frequency Detection 2
1: Output frequency ≥ L4-01
bit 6
Drive ready
1: Run ready
bit 7
During low voltage detection
1: During detection
bit 8
During baseblock
1: Drive output during baseblock
bit 9
Frequency reference mode
1: No communication option, 0: Communication option
bit A
Run command mode
1: No communication option, 0: Communication option
bit B During overtorque/undertorque 1, 2 detection
bit C
Frequency reference loss
1: Loss
bit D
Restart Enabled
1: Restart Enabled
bit E
Faults
1: Fault generated
bit F
Modbus communications timeout
1: At Timeout
002D
U1-11 [Out Terminal Status]
bit 0
MFDO (terminal 2NO-2CM)
1: ON, 0: OFF
bit 1
MFDO (terminal 3NO-3CM)
1: ON, 0: OFF
bit 2
MFDO (terminal 4NO-4CM)
1: ON, 0: OFF
bit 3 - 6 Reserved
bit 7
Fault relay output (terminal 1NO/1NC-1CM)
1: ON, 0: OFF
bit 8 - F Reserved
002E Reserved
