6.2 Modbus Communications
232 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Register No.
(Hex.)
Description
0098 - 0099
U4-01 [Cumulative OpeTime]
(Ex.) When U4-01 is 12345, 0098 (Hex.) = 1234 and 0099 (Hex.) = 5.
009A - 009B
U4-03 [Fan Oper.Time]
(Ex.) When U4-03 is 12345, 009A (Hex.) = 1234 and 009B (Hex.) = 5.
009C - 00AA Reserved
00AB
Drive rated current
Note:
The unit of display is different for different models.
4002 to 4023: 0.01 A
4031 to 4675: 0.1 A
00AC
Motor Speed
Units: min
-1
or r/min
Note:
Set Motor Pole Count E2-04, E4-04, E5-04, E9-08.
00AD
Units: 0.01%
00AE, 00AF Reserved
Option codes connected to
CN5-A
The drive stores option codes in the register.
AI-A3 = 0003 (Hex.)
AO-A3 = 0004 (Hex.)
DI-A3 = 0001 (Hex.)
DO-A3 = 0002 (Hex.)
PG-B3 = 0011 (Hex.)
PG-F3 = 0021 (Hex.)
PG-RT3 = 0023 (Hex.)
PG-X3 = 0012 (Hex.)
SI-C3 = 5343 (Hex.)
SI-EM3 = 1005 (Hex.)
SI-EN3 = 1006 (Hex.)
SI-ET3 = 1004 (Hex.)
SI-N3 = 534E (Hex.)
SI-P3 = 5350 (Hex.)
SI-S3 = 5353 (Hex.)
SI-T3 = 5354 (Hex.)
SI-W3 = 1003 (Hex.)
00B1 Reserved
00B2 Option codes connected to CN5-B
00B3 Option codes connected to CN5-C
00B4 Reserved
00B5
U1-16 [SFS Output
Frequency]
Units: min
-1
or r/min
Note:
Set Motor Pole Count E2-04, E4-04, E5-04, E9-08.
00B6
Units: 0.01%
00B7
Frequency reference
monitor
Units: min
-1
or r/min
Note:
Set Motor Pole Count E2-04, E4-04, E5-04, E9-08.
00B8
Units: 0.01%
00B9 - 00BE Reserved
00BF
Operation error number
xx of oPExx is displayed.
