Omron Q2A Series Technical Manual

10.2 Model Specifications (400 V Class)
352 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Model
Input
Voltage
Duty
Rating
4002 4004 4005 4007 4009 4012 4018 4023
Power
Supply
Rated Voltage/Rated Frequency
• Three-phase AC power supply 380 V to 480 V at 50/60 Hz
• DC power supply 513 V to 679 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
< 460 V
HD 1.5 2.8 3.7 5.3 7.1 9.3 13 17
ND 2.0 3.7 5.3 7.1 9.3 13 17 24
≥ 460 V
HD 1.3 1.7 3.2 4.6 6.1 7.5 11 15
ND 2.1 4.0 5.6 7.5 9.1 13 18 26
*1 The maximum applicable motor output complies with 380 V motor ratings as specified in Annex G of IEC 60947-4-1. The rated
output current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output complies with 460 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*3 Assumes the value at the rated output current. The input current rating changes when the power supply transformer, input reactor,
wiring connections, or power supply impedance change.
*4 The rated output capacity is calculated with a rated output voltage of 380 V.
*5 The rated output capacity is calculated with a rated output voltage of 460 V.
Table 10.3 Rating (400 V Class)
Model
Input
Voltage
Duty Rating 4031 4038 4044 4060 4075 4089 4103
Maximum Applicable Motor
Output (kW)
< 460 V
*1
HD 11 15 18.5 22 30 37 45
ND 15 18.5 22 30 37 45 55
≧ 460 V
*2
HD 11 15 18.5 22 30 37 45
ND 15 18.5 22 30 37 45 55
Maximum Applicable Motor
Output (HP)
< 460 V
*1
HD 15 20 25 30 40 50 60
ND 20 25 30 40 50 60 75
≧ 460 V
*2
HD 15 20 25 30 40 50 60
ND 20 25 30 40 50 60 75
Input
Rated Input
Current (A)
*3
< 460 V
HD (AC) 30.6 41.3 50.5 43.1 58.3 71.5 86.5
HD (DC) 38 51 62 53 72 88 106
ND (AC) 41.3 50.5 59.7 58.3 71.5 86.5 105
ND (DC) 51 62 74 72 88 106 129
≥ 460 V
HD (AC) 25.3 34.1 41.7 35.6 48.1 59.0 71.4
HD (DC) 31 42 52 44 59 73 88
ND (AC) 34.1 41.7 49.4 48.1 59.0 71.4 86.9
ND (DC) 42 52 61 59 73 88 107
