Specifications
10
10.3 Drive Specifications
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 359
Environment Conditions
Surrounding Area
Pollution degree 2 (IEC 62477-1) or less
Install the drive in an area without:
• Oil mist, corrosive or flammable gas, or dust
• Metal powder, oil, water, or other unwanted materials
• Radioactive materials or flammable materials, including wood
• Harmful gas or fluids
• Salt
• Direct sunlight
Keep wood and other flammable materials away from the drive.
Altitude
1000 m (3281 ft.) maximum
Note:
Derate the output current by 1% for each 100 m (328 ft.) to install the drive in altitudes between 1000 m to 4000 m (3281 ft. to 13123 ft.).
It is not necessary to derate the rated voltage in these conditions:
• Installing the drive at 2000 m (6562 ft.) or lower
• Installing the drive between 2000 m to 4000 m (6562 ft. to 13123 ft.) and grounding the neutral point on the power supply.
Contact the manufacturer or your nearest sales representative when not grounding the neutral point.
Vibration
• 10 Hz to 20 Hz: 1 G (9.8 m/s
2
, 32.15 ft/s
2
)
• 20 Hz to 55 Hz:
4002 to 4168: 0.6 G (5.9 m/s
2
, 19.36 ft/s
2
)
4208 to 4675: 0.2 G (2.0 m/s
2
, 6.56 ft/s
2
)
Installation
Orientation
Install the drive vertically for sufficient cooling airflow.
Table 10.9 Standard
Item
Specification
Harmonized Standard
• UL61800-5-1
• EN61800-3
• IEC/EN61800-5-1
• Two Safe Disable inputs and one EDM output according to ISO/EN13849-1:2015 (Cat. 3, PLe), IEC/EN61508:2010 (SIL3)
Protection Design
Open-chassis type (IP20)
Enclosed wall-mounted type (UL Type 1)
Note:
Install a UL Type 1 kit on an open-chassis type (IP20) drive to convert the drive to a wall-mount enclosure (UL Type 1).
