10.5 Drive Watt Loss
366 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4007 6.9
2 50 42 92
4009 7.6
2 35 49 84
4012 11
2 49 76 125
4018 14
2 64 112 176
4023 21
2 87 158 245
4031 27
2 109 188 297
4038 34
2 116 234 350
4044 40
2 137 296 433
4060 52
2 133 379 512
4075 65
2 156 450 606
4089 77
2 180 569 749
4103 96
2 229 698 927
4140 124
2 334 982 1316
4168 156
2 481 1199 1680
4208 180
2 429 1275 1704
4250 240
2 648 1643 2291
4296 302
2 817 2257 3074
4371 361
2 975 2561 3536
4389 414
2 873 2422 3295
4453 477
2 1183 3329 4512
4568 515
2 1320 3697 5017
4675 -
- - - -
