Omron Q2A Series Technical Manual

11.15 U: MONITORS
474 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description MFAO Signal Level Ref.
U1-12
(004B)
Drive Status Shows drive status where 1 = (ON) and 0 = (OFF).
For example, U1-12 shows “00000101” during run with the Reverse Run command.
bit 0 : During run
bit 1 : During zero-speed
bit 2 : During reverse
bit 3 : During fault reset signal input
bit 4 : During speed agreement
bit 5 : Drive ready
bit 6 : During minor fault detection
bit 7 : During fault detection
No signal output
available
-
U1-13
(004E)
Terminal AI1 Input Lv Shows the signal level of terminal AI1.
Unit: 0.1%
10 V = 100% (-10 V to
+10 V)
-
U1-14
(004F)
Terminal AI2 Input Lv Shows the signal level of terminal AI2.
Unit: 0.1%
10 V = 100% (-10 V to
+10 V)
-
U1-15
(0050)
Terminal AI3 Input Lv Shows the signal level of terminal AI3.
Unit: 0.1%
0 V = 100% (-10 V to
+10 V)
-
U1-16
(0053)
SFS Output Frequency Shows the output frequency after soft start. Shows the frequency with acceleration and
deceleration times and Jerk Control. Parameter o1-03 [FrqDisplay Unit Selection]
selects the units.
Unit: 0.01 Hz
10 V = Max. frequency
(-10 V to +10 V)
-
U1-17
(0058)
DI-A3 Input Status Shows the reference value input from DI-A3 option.
Shows the input signal for DI-A3 in hexadecimal as set in F3-01 [D.In Funct
Selection].
3FFFF: Set (1 bit) + Sign (1 bit) + 16 bit
No signal output
available
-
U1-18
(0061)
oPE Fault Parameter Shows the parameter number that caused the oPE02 [Parameter Range Setting Error]
or oPE08 [Parameter Selection Error].
No signal output
available
-
U1-19
(0066)
Modbus Err.Code Shows the contents of the Modbus communication error where 1 = (error) and 0 = (no
error).
For example, U1-19 shows “00000001” when a CRC error occurs.
bit 0 : CRC Error
bit 1 : Data Length Error
bit 2 : Not used (normal value of 0).
bit 3 : Parity Error
bit 4 : Overrun Error
bit 5 : Framing Error
bit 6 : Timed Out
bit 7 : Not used (normal value of 0).
No signal output
available
-
U1-21
(0077)
AI-A3 Term V1 Level Shows the analog reference of terminal V1 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to
+10 V)
-
U1-22
(072A)
AI-A3 Term V2 Level Shows the analog reference of terminal V2 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to
+10 V)
-
U1-23
(072B)
AI-A3 Term V3 Level Shows the analog reference of terminal V3 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to
+10 V)
-
U1-24
(007D)
Input Pulse Monitor Shows the frequency to pulse train input terminal PI.
Unit: 1 Hz
Determined by H6-02 -
U1-25
(004D)
SoftNumber Flash Shows the FLASH ID. No signal output
available
-
U1-26
(005B)
SoftNumber ROM Shows the ROM ID. No signal output
available
-
U1-50
(1199)
Expert
Virt. Analog Input Shows the virtual analog input value. Determined by H7-40 -
U1-91
(154E)
Expert
Output Voltage Shows the drive internal output voltage reference.
Unit: 0.1 V
400 V class: 10 V = 400
Vrms
-
