12.3 C: TUNING
566 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
■ C1-01 Accel Time 1
No.
(Hex.)
Name Description
Default
(Range)
C1-01
(0200)
RUN
Accel Time 1
Sets the length of time to accelerate from zero to maximum output frequency.
10.0 s
(0.0 - 6000.0 s)
Note:
When C1-10 = 0 [Ac/Dec Units = 0.01s], the setting range is 0.00 to 600.00 s.
■ C1-02 Decel Time 1
No.
(Hex.)
Name Description
Default
(Range)
C1-02
(0201)
RUN
Decel Time 1
Sets the length of time to decelerate from maximum output frequency to zero.
10.0 s
(0.0 - 6000.0 s)
Note:
When C1-10 = 0 [Ac/Dec Units = 0.01s], the setting range is 0.00 to 600.00 s.
■ C1-03 Accel Time 2
No.
(Hex.)
Name Description
Default
(Range)
C1-03
(0202)
RUN
Accel Time 2
Sets the length of time to accelerate from zero to maximum output frequency.
10.0 s
(0.0 - 6000.0 s)
Note:
When C1-10 = 0 [Ac/Dec Units = 0.01s], the setting range is 0.00 to 600.00 s.
■ C1-04 Decel Time 2
No.
(Hex.)
Name Description
Default
(Range)
C1-04
(0203)
RUN
Decel Time 2
Sets the length of time to decelerate from maximum output frequency to zero.
10.0 s
(0.0 - 6000.0 s)
Note:
When C1-10 = 0 [Ac/Dec Units = 0.01s], the setting range is 0.00 to 600.00 s.
■ C1-05 Accel Time 3
No.
(Hex.)
Name Description
Default
(Range)
C1-05
(0204)
RUN
Accel Time 3
Sets the length of time to accelerate from zero to maximum output frequency.
10.0 s
(0.0 - 6000.0 s)
Note:
When C1-10 = 0 [Ac/Dec Units = 0.01s], the setting range is 0.00 to 600.00 s.
■ C1-06 Decel Time 3
No.
(Hex.)
Name Description
Default
(Range)
C1-06
(0205)
RUN
Decel Time 3
Sets the length of time to decelerate from maximum output frequency to zero.
10.0 s
(0.0 - 6000.0 s)
Note:
When C1-10 = 0 [Ac/Dec Units = 0.01s], the setting range is 0.00 to 600.00 s.
