12.6 F: OPTIONS
642 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Terminal V1 will output an analog signal = 100% of the parameter set in F4-01.
4. View the monitor connected to terminal V1 and adjust F4-05.
• Use Gain and Bias to Adjust the Output Signal Level of Terminal V2
You must stop the drive to adjust the output signal. Use this procedure to calibrate the drive:
1. View the F4-04 [Term.V2 Gain] value on the keypad.
Terminal V2 will output a voltage = 100% of the monitor set in F4-03 [Term.V2 Function Selection].
2. View the monitor connected to terminal V2 and adjust F4-04.
3. View the F4-06 [Term.V2 Bias] value on the keypad.
The analog signal equal to 0% of the parameter being set in F4-03 will be output from terminal V2.
4. View the monitor connected to terminal V2 and adjust F4-06.
■ F4-01 Term.V1 Funct Selection
No.
(Hex.)
Name Description
Default
(Range)
F4-01
(0391)
Term.V1 Funct Selection
Sets the monitor signal output from terminal V1.
102
(000 - 999)
Enter the last three digits of Ux-xx [MONITORS] to set monitor data to output from the option card. For example,
set x-xx to 102 to monitor U1-02 [Output Frequency].
Note:
• You cannot use all of the monitors in all of the control methods.
• When you use the terminal in through mode, set 000 or 031. You can use this setting to adjust the V1 terminal output from PLC
through Modbus communications or a communications option.
■ F4-02 Term.V1 Gain
No.
(Hex.)
Name Description
Default
(Range)
F4-02
(0392)
RUN
Term.V1 Gain
Sets the gain of the monitor signal that is sent from terminal V1. Sets the analog signal output
level from the terminal V1 at 10 Vor 20 mA as 100% when an output for monitoring items is
100%.
100.0%
(-999.9 - +999.9%)
The maximum output voltage output from terminal V1 is ±10 V. Use F4-07 [Term.V1 Level of Signal] to set the
signal level.
Example settings:
When you use these settings, and the monitored output voltage is at 100% (drive rated current), the output voltage
of terminal V1 is 5 V (50% of 10 V). The output current is 200% of the drive rated current when terminal V1
outputs a maximum voltage of 10 V.
• F4-01 [Term.V1 Funct Selection] = 102 (U1-02: Output Frequency)
• F4-02 = 50.0%
• F4-05 [Term.V1 Bias] = 0.0%
• F4-07 = 0 (0 to 10V)
■ F4-03 Term.V2 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
F4-03
(0393)
Term.V2 Function Selection
Sets the number for monitor item of output from terminal V2.
103
(000 - 999)
Enter the last three digits of Ux-xx [MONITORS] to set monitor data to output from the option card. For example,
set x-xx to 103 to monitor U1-03 [Output Current].
Note:
• You cannot use all of the monitors in all of the control methods.
• When you use the terminal in through mode, set 000 or 031. You can use this setting to adjust the V2 terminal output from PLC
through Modbus communications or a communications option.
