12.6 F: OPTIONS
658 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
■ F6-61 DNet Time Scale
No.
(Hex.)
Name Description
Default
(Range)
F6-61
(03DC)
DNet Time Scale
Sets the time scale of the DeviceNet communication master.
0
(-15 - +15)
■ F6-62 DNet Heartbeat Interval
No.
(Hex.)
Name Description
Default
(Range)
F6-62
(03DD)
DNet Heartbeat Interval
Sets the heartbeat for DeviceNet communication. Set this parameter to 0 to disable the heartbeat
function.
0
(0 - 10)
■ F6-63 DNet Network MAC ID
No.
(Hex.)
Name Description
Default
(Range)
F6-63
(03DE)
DNet Network MAC ID
Sets the function to see the actual DeviceNet MAC address using the keypad. This parameter
functions as a monitor only.
0
(0 - 63)
■ F6-64 to F6-67 DynOut.Ass109 P1 to P4
No.
(Hex.)
Name Description
Default
(Range)
F6-64 to F6-67
(03DF - 03E2)
DynOut.Ass109 P1 to P4
Sets Configurable Outputs 1 to 4 written to the Modbus register.
0000h
(0000h - FFFFh)
■ F6-68 to F6-71 DynIn.Ass159 P1 to 4
No.
(Hex.)
Name Description
Default
(Range)
F6-68 to F6-71
(03E3, 03E4,
03C7, and 03C8)
DynIn.Ass159 P1 to 4
Sets Configurable Inputs 1 to 4 written to the Modbus register.
0000h
(0000h - FFFFh)
■ F6-72 PowerLink Address
No.
(Hex.)
Name Description
Default
(Range)
F6-72
(081B)
PowerLink Address
Sets the node ID for PowerLink communication.
0
(0 - 255)
■ F7-01 IP Address 1
No.
(Hex.)
Name Description
Default
(Range)
F7-01
(03E5)
IP Address 1
Sets the first octet of the IP Address for the device that is connecting to the network. Restart the
drive after you change this parameter.
192
(0 - 255)
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to IP Address 4] to set the IP Address. Be sure to set a different IP address for each drive
on the network.
• Also set parameters F7-01 to F7-12.
■ F7-02 IP Address 2
No.
(Hex.)
Name Description
Default
(Range)
F7-02
(03E6)
IP Address 2
Sets the second octet of the IP Address for the device that is connecting to the network. Restart the
drive after you change this parameter.
168
(0 - 255)
