Parameter Details
12
12.7 H: TERMINALS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 673
■ C: MultSpd Ref3
Setting Function Description
C MultSpd Ref3
Uses speed references d1-01 to d1-08 [Reference 1 to Reference 8] to set a multi-step speed reference.
Note:
Refer to “Setting Procedures for Multi-step Speed Operation” in “d: REFERENCE” for more information.
■ D: MultSpd Ref4
Setting Function Description
D MultSpd Ref4
Sets the command to switch d1-09 to d1-16 [Reference 9 to Reference 16] with multi-step speed references 1, 2 and 3.
Note:
Refer to “Setting procedure for the multi-step speed operation” for more information.
■ E: Offset Frq 1
Setting Function Description
E Offset Frq 1
Sets the function to add the offset frequency set in d7-01 [Offset Frq 1] to the frequency reference when the terminal activates.
Note:
Refer to “d7: OFFSET FREQUENCY” for more information.
■ F: Offset Frq 2
Setting Function Description
F Offset Frq 2
Sets the function to add the offset frequency set in d7-02 [Offset Frq 2] to the frequency reference when the terminal activates.
Note:
Refer to “d7: OFFSET FREQUENCY” for more information.
■ 10: Offset Frq 3
Setting Function Description
10 Offset Frq 3
Sets the function to add the offset frequency set in d7-03 [Offset Frq 3] to the frequency reference when the terminal activates.
Note:
Refer to “d7: OFFSET FREQUENCY” for more information.
■ 11: LOC/REM Sel.
Setting Function Description
11 LOC/REM Sel.
Sets drive control for the keypad (LOCAL) or an external source (REMOTE).
Note:
• When the MFDI terminal sets the LOCAL/REMOTE selection, on the keypad is disabled.
• When LOCAL Mode is selected, the green light for comes on.
• When the Run command is ON, you cannot switch between LOCAL Mode and REMOTE Mode.
ON : LOCAL
The keypad is the Frequency reference source and Run command source.
OFF : REMOTE
The frequency reference and Run command settings are set in b1-01, b1-02 [Run Comm. Sel 1] or b1-15, b1-16
[Run Comm. Sel 2].
