Parameter Details
12
12.7 H: TERMINALS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 695
The drive stops the motor in the deceleration time set in C1-09 [Fast Stop Time]. Fault relay output terminal 1NO-
1CM activates and terminal 1NC-1CM deactivates.
3 : Alarm Only
The keypad shows “CP2” and the drive continues operation at the current frequency reference.
Note:
The output terminal set for Alarm [H2-01 to H2-03 = 4] activates.
4 : Low Speed (L8-19)
■ H2-36 Compare1 HoldTime
No.
(Hex.)
Name Description
Default
(Range)
H2-36
(159E)
Compare1 HoldTime
Sets the length of time that CP1 [Comparator1 Limit Fault] is disabled.
0.0 s
(0.0 - 10.0 s)
Note:
• After you enter a Run command and wait for the time set in this parameter, the drive will monitor operation and make sure that it is in
the Comparator 1 range until you enter the Stop command.
• When CP1 detection is disabled, the drive will trigger a digital output.
■ H2-37 Compare2 HoldTime
No.
(Hex.)
Name Description
Default
(Range)
H2-37
(159F)
Compare2 HoldTime
Sets the length of time that CP2 [Comparator2 Limit Fault] is disabled.
0.0 s
(0.0 - 10.0 s)
Note:
• After you enter a Run command and wait for the time set in this parameter, the drive will monitor operation and make sure that it is in
the Comparator 2 range until you enter the Stop command.
• When CP2 detection is disabled, the drive will trigger a digital output.
■ H2-40 Mbus 15E0h b0 Output Function
No.
(Hex.)
Name Description
Default
(Range)
H2-40
(0B58)
Mbus 15E0h b0 Output
Function
Sets the MFDO for bit 0 of Modbus register 15E0 (Hex.).
0
(0 - 1A7)
■ H2-41 Mbus 15E0h b1 Output Function
No.
(Hex.)
Name Description
Default
(Range)
H2-41
(0B59)
Mbus 15E0h b1 Output
Function
Sets the MFDO for bit 1 of Modbus register 15E0 (Hex.).
0
(0 - 1A7)
■ H2-42 Mbus 15E0h b2 Output Function
No.
(Hex.)
Name Description
Default
(Range)
H2-42
(0B5A)
Mbus 15E0h b2 Output
Function
Sets the MFDO for bit 2 of Modbus register 15E0 (Hex.).
0
(0 - 1A7)
■ H2-60 2NO-2CM 2nd Function
No.
(Hex.)
Name Description
Default
(Range)
H2-60
(1B46)
Expert
2NO-2CM 2nd Function
Selects the second function for terminal 2NO-2CM. The logical calculation results of the
terminals assigned to functions by H2-01 [2NO-2CM Func Selection] is output.
0
(0 - A7)
