12.7 H: TERMINALS
736 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
■ H7-40 Virtual AOut Enable
No.
(Hex.)
Name Description
Default
(Range)
H7-40
(1163)
Virtual AOut Enable
Sets the signal level of the virtual analog output.
1
(1 - 3)
1 : 0-100 (Absolute Value)
2 : -10 +10 VDC
3 : 0-10 VDC
■ H7-41 Virtual AOut Select Function
No.
(Hex.)
Name Description
Default
(Range)
H7-41
(1164)
Virtual AOut Select
Function
Sets the monitor to be output from the virtual analog output. Set the x-xx part of the Ux-xx
[MONITOR]. For example, set x-xx to 102 to monitor U1-02 [Output Frequency].
102
(0 - 999)
■ H7-42 Virtual AOut Filter Time
No.
(Hex.)
Name Description
Default
(Range)
H7-42
(1165)
Virtual AOut Filter Time
Sets the time constant for a primary filter of the virtual analog output.
0.00 s
(0.00 - 2.00 s)
