Parameter Details
12
12.10 o: KEYPAD
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 811
■ o2-02 STOP Key Selection of Function
No.
(Hex.)
Name Description
Default
(Range)
o2-02
(0506)
STOP Key Selection of
Function
Sets the function to stop the drive with the button on the keypad when the Run command
source for the drive is REMOTE (external) and not assigned to the keypad.
1
(0, 1)
0 : Disabled
1 : Enabled
stays enabled when the Run command source has not been assigned to the keypad.
To start the drive again after you push to stop operation, turn the external Run command OFF and ON
again.
■ o2-03 UserPar Set Default Values
No.
(Hex.)
Name Description
Default
(Range)
o2-03
(0507)
UserPar Set Default Values
Sets the function to keep the settings of changed parameters as user parameter defaults to use
during initialization.
0
(0 - 2)
When you set this parameter to 1, the drive saves changed parameter settings as user parameter setting values in a
part of the memory that is isolated from drive parameters.
When you set A1-03 = 1110 [Init Parameters = User / Solution Initialization] to initialize the drive, the drive
resets the internal parameter setting values to those user parameter setting values.
0 : No change
1 : Set defaults
Saves changed parameter settings as user-set default for User Initialization.
Set o2-03 = 1 [Set defaults], then push on the keypad to save the user parameter setting values. After the drive
saves the setting value, o2-03 automatically resets to 0.
2 : Clear all
Deletes all of the saved user parameter setting values.
To delete the user parameter setting values, set this parameter to 2 and push on the keypad. The drive will
automatically reset o2-03 to 0. If you delete the user parameter setting values, you cannot set A1-03 = 1110 to
initialize parameters.
■ o2-04 Drive KVA Selection
No.
(Hex.)
Name Description
Default
(Range)
o2-04
(0508)
Drive KVA Selection
Sets the Drive Model code. Set this parameter after replacing the control board.
Determined by the drive
(-)
NOTICE: Set o2-04 [Drive KVA Selection] correctly. Failure to obey will decrease drive performance, cause the protection
function to operate incorrectly, and cause damage to the drive.
Note:
When the setting value of o2-04 changes, related parameter setting values also change. Refer to Defaults by Drive Model and Duty
Rating ND/HD on page 489 for more information.
These tables list the relation between o2-04 setting values and drive models.
o2-04 Setting Drive Model
62 2004
63 2006
65 2010
66 2012
67 2018
o2-04 Setting Drive Model
68 2021
6A 2030
6B 2042
6D 2056
6E 2070
