12.11 T: AUTOTUNING
828 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
1 : SPM Motor
■ T2-04 PMMot Rated Power
No.
(Hex.)
Name Description
Default
(Range)
T2-04
(0730)
PMMot Rated Power
Sets the rated output power (kW) of a PM motor.
Determined by o2-04 and
C6-01
(0.00 - 650.00 kW)
Note:
Capacities 300 kW and less are set in units of 0.01 kW. Capacities above 300 kW are set in units of 0.1 kW. The maximum applicable
motor output varies depending on the setting of C6-01 [ND/HD Duty Selection].
■ T2-05 PMMot Rated Voltage
No.
(Hex.)
Name Description
Default
(Range)
T2-05
(0732)
PMMot Rated Voltage
Sets the rated voltage (V) of the motor.
400 V Class: 400.0 V
(400 V Class: 0.0 - 510.0
V)
■ T2-06 PMMot Rated Current
No.
(Hex.)
Name Description
Default
(Range)
T2-06
(0733)
PMMot Rated Current
Sets the rated current (A) of the motor.
Determined by o2-04
(10% to 200% of the drive
rated current)
■ T2-07 PMMot Base Frequency
No.
(Hex.)
Name Description
Default
(Range)
T2-07
(0753)
PMMot Base Frequency
Sets the base frequency (Hz) of the motor.
87.5 Hz
(0.0 - 590.0 Hz)
■ T2-08 PMMot Poles Number
No.
(Hex.)
Name Description
Default
(Range)
T2-08
(0734)
PMMot Poles Number
Sets the number of motor poles.
6
(2 - 48)
■ T2-09 PMMot Base Speed
No.
(Hex.)
Name Description
Default
(Range)
T2-09
(0731)
PMMot Base Speed
Sets the motor base speed (min
-1
(r/min)).
1750 min
-1
(r/min)
(0 - 34500 min
-1
(r/min))
■ T2-10 PMMot Stator Resistance
No.
(Hex.)
Name Description
Default
(Range)
T2-10
(0754)
PMMot Stator Resistance
Sets the stator resistance for each motor phase.
Determined by T2-02
(0.000 - 65.000 Ω)
Note:
This parameter does not set line-to-line resistance.
■ T2-11 PMMot dAxis Inductance
No.
(Hex.)
Name Description
Default
(Range)
T2-11
(0735)
PMMot dAxis Inductance
Sets the d-axis inductance of the motor on a per phase basis.
Determined by T2-02
(0.00 - 600.00 mH)
