A-103
Appendicies
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
A-3 Sysmac Error Status Codes
App
A-3-1 Error Table
08020000 hex Fan Warning The fan stop state
continued for 1
second.
• There is foreign matter in the
fan.
• The Servo Drive failed.
page A-152
08040000 hex External
Encoder
Overheating
Warning
The external
encoder
temperature
exceeded the
specified value.
• The ambient temperature is too
high.
• Linear Motor failed.
page A-153
08050000 hex Life
Expectancy
Warning
The remaining life
of the capacitor or
the fan is shorter
than the specified
value.
• The life expectancy of the
capacitor or the fan is shorter
than the specified value.
page A-153
08060000 hex External
Encoder
Error
Warning
The external
encoder detected a
warning.
• There is insufficient power
supply voltage for the external
encoder.
• Noise is entering on the
external encoder connector
cable.
• The external encoder failed.
page A-154
08070000 hex External
Encoder
Communicati
ons Warning
The external
encoder had more
communications
errors than the
specified value.
• There is insufficient power
supply voltage for the external
encoder.
• Noise is entering on the
external encoder connector
cable.
page A-154
34E00000 hex Data Setting
Warning
An object setting is
out of range.
• An object setting is out of
range.
page A-155
383C0000 hex Overload
Warning
The load ratio is
85% or more of the
protection level.
• Overload
• There is incorrect wiring of the
motor line or a broken cable.
page A-155
383D0000 hex Excessive
Regeneration
Warning
The regeneration
load ratio is 85% or
more of the level.
• There is excessive
regeneration.
• Th
is Regeneration Resistor
cannot be used for continuous
regenerative braking.
page A-156
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
