7 Appendix A
&,
Models B4550 to B430K
Inverter model 3G3IV-
-
380 to 460 V
B4550 B4750 B411K B416K B418K B422K B430K
Max. applicable motor
output Hp (kW) (See
Rated output 75
(55)
100
(75)
150
(110)
200
(160)
250
(185)
300
(220)
400
(300)
Note 1)
Max. continuous output 100
(75)
150
(110)
200
(160)
250
(185)
300
(220)
400
(300)
500
(355)
Output characteristics Inverter capacity kVA 110 140 200 250 290 380 510
Rated output current A 128 165 224 300 340 450 600
Max. continuous output
current (See Note 2) A
144 180 252 337 380 506 675
Max. output voltage 3-phase, 380/400/415/440/460 V (Proportional to input
voltage)
Rated output frequency 50, 60, 72, 90, 120, 180 Hz (up to 400 Hz available)
Power Supply Rated input voltage and
frequency
3-Phase 380/400/415/440/460 V, 50/60 Hz
Allowable voltage fluctuation ±10%
Allowable frequency
fluctuation
±5%
Control characteristics Control method Sine wave PWM
Frequency control range 0.1 to 400 Hz
Frequency accuracy Digital command: 0.01%, +14° to 104°F, -- 10 ° to 40°C
Analog command: 0.1%, 77°
±
18°F, 25°
±
10°C
Frequency resolution Digital operator reference: 0.1 Hz
Analog reference: 0.06 Hz/60 Hz
Control characteristics Output frequency resolution 0.01 Hz (1/30000)
Overload capacity 150% rated output current for one minute/
110% max. continuous output current for one minute
Frequency setting signal 0to10VDC(20kΩ),4to20mA(250Ω),
0
±
10 V (OPTIONAL)
Accel/Decel time 0.1 to 6000 sec. (Accel/Decel time setting independently)
Braking torque Approx. 20%
No. of V-f patterns
(Total of 16)
4: For general purpose
4: For high starting torque:
4: For fans and pumps
3: For machine tools.
Protective functions Motor overload protection Electric thermal overload relay
Instantaneous overcurrent Motor coasts to a stop at approx. 200% rated current.
Fuse blown protection Motor coasts to a stop by blown-fuse.
Overload Motor coasts to a stop for 1 minute at 150% rated output
current./motor coasts to a stop for 1 minute at 110% max.
continuous output current.
Overvoltage Motor coasts to a stop if converter output voltage exceeds
800 V. (approx. 700 V) (see Note 3)
Undervoltage Motor coasts to a stop if converter output voltage drops to
420 V or below.
Momentary power loss Immediately stop by 15 ms and above momentary power loss.
(Continuous system operation during power loss less than 2
sec is equipped as standard.) Setting made before shipment.
Fin overheat Thermostat
