10-4
D Gearmotor
The speed range for continuous operation differs according to the lubrication method
and
motor manufacturer . In particular , the continuous operation of an oil-lubricated mo -
tor
in the low speed range may result in burning. If the motor is to be operated at a speed
higher than 60 Hz, consult with the manufacturer.
D Synchronous Motor
A synchronous motor is not suitable for Inverter control.
If
a group of synchronous motors is individually turned on and of f, synchronism may be
lost.
D Single-phase Motor
Do not use the Inverter for a single-phase motor.
The motor should be replaced with a 3-phase motor.
H Power T ransmission Mechanism (Speed Reducers, Belts, and
Chains)
If an oil-lubricated gear box or speed reducer is used in the power transmission mecha -
nism, oil lubrication will be affected when the motor operates only in the low speed
range.
The power transmission mechanism will make noise and experience problems
with service life and durability if the motor is operated at a speed higher than 60 Hz.
H Motor Burnout Caused by Insufficient Dielectric Strength of
Each Phase of Motor
Surge occurs among the phases of the motor when the output voltage is switched.
If
the dielectric strength of each phase of the motor is insuf ficient, the motor may burn
out.
The dielectric strength of each phase of the motor must be higher than the maximum
surge
voltage. Normally , the maximum surge voltage is approximately three times the
power voltage imposed on the Inverter.
Using Inverter for Motor Chapter 10

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
