Omron SYSDRIVE 3G3JV Series User Manual

5-15
5-6 Setting the Acceleration/Deceleration Time
The following description provides information on parameters related to
acceleration and deceleration time settings.
Trapezoidal
and S-shape acceleration and deceleration are available. Us -
ing the S-shape characteristic function for acceleration and deceleration
can reduce shock to the machinery when stopping or starting.
H Setting the Acceleration/Deceleration Time (n16 through n19)
•Two acceleration times and two deceleration times can be set.
•The
acceleration time is the time required to go from 0% to 100% of the maximum fre -
quency and the deceleration time is the time required to go from 100% to 0% of the
maximum
frequency . The actual acceleration or deceleration time is obtained from the
following formula.
Acceleration/Deceleration time = (Acceleration/Deceleration time set value)
×
(Frequency reference value) ÷ (Max. frequency)
Acceleration time 2 and deceleration time 2 are enabled by setting 1 1 for acceleration/
deceleration time selection in any of the n36 through n39 parameters for multi-function
input.
Deceleration time 2 is also enabled by emergency-stop settings 19, 20, 21, and 22 in
any
of the n36, n37, n38, and n39 parameters for multi-function input with n04 for inter -
ruption mode selection set to 0 (i.e., deceleration stop).
n16 Acceleration time 1 Changes during
operation
Yes
Setting
range
0.0 to 999 (s) Unit of
setting
0.1 s
(see note)
Default setting 10.0
n17 Deceleration Time 1 Changes during
operation
Yes
Setting
range
0.0 to 999 (s) Unit of
setting
0.1 s
(see note)
Default setting 10.0
n18 Acceleration Time 2 Changes during
operation
Yes
Setting
range
0.0 to 999 (s) Unit of
setting
0.1 s
(see note)
Default setting 10.0
n19 Deceleration Time 2 Changes during
operation
Yes
Unit of
setting
0.0 to 999 (s) Unit of
setting
0.1 s
(see note)
Default setting 10.0
Note Values will be set in 0.1-Hz increments if the frequency is less than 100 Hz and
1-Hz increments if the frequency is 100 Hz or over.
Basic Operation Chapter 5

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
