Omron SYSDRIVE 3G3JV Series User Manual

5-4
5-2 V/f Control
H Setting the V/f Patterns (n09 to n15)
•Set the V/f pattern so that the motor output torque is adjusted to the required load
torque.
•The
3G3JV incorporates an automatic torque boost function. Therefore, a maximum of
150% torque can be output at 3 Hz without changing the default settings. Check the
system in trial operation and leave the default settings as they are if no torque charac -
teristic changes are required.
n09 Maximum Frequency (FMAX) Changes during
operation
No
Setting
range
50.0 to 400 (Hz) Unit of
setting
0.1 Hz
(see note)
Default setting 60.0
n10 Maximum Voltage (VMAX) Changes during
operation
No
Setting
range
1 to 255 (V) Unit of
setting
1 V Default settings 200
n11 Maximum Voltage Frequency (FA) Changes during
operation
No
Setting
range
0.2 to 400 (Hz) Unit of
setting
0.1 Hz
(see note)
Default setting 60.0
n12 Middle Output Frequency (FB) Changes during
operation
No
Setting
range
0.1 to 399 (Hz) Unit of
setting
0.1 Hz
(see note)
Default setting 1.5
n13 Middle Output Frequency Voltage (VC) Changes during
operation
No
Setting
range
1 to 255 (V) Unit of
setting
1 V Default setting 12
n14 Minimum Output Frequency (FMIN) Changes during
operation
No
Setting
range
0.1 to 10.0 (Hz) Unit of
setting
0.1 Hz Default setting 1.5
n15 Minimum Output Frequency Voltage (VMIN) Changes during
operation
No
Setting
range
1 to 50 (V) Unit of
setting
1 V Default setting 12
Basic Operation Chapter 5

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
