Omron SYSDRIVE 3G3JV Series User Manual

1-2
1-1 Function
The compact simple SYSDRIVE 3G3JV-Series Inverter ensures greater
ease of use than any conventional model.
The 3G3JV Inverter meets EC Directives and UL/cUL standard require-
ments for worldwide use.
H SYSDRIVE 3G3JV Inverter Models
•The following 3- and single-phase 200-VAC-class 3G3JV models are available.
Rated voltage Protective
structure
Maximum applied
motor capacity
Model
3-phase 200 VAC Closed,
ll ti t
0.1 (0.1) kW 3G3JV-A2001
3 p ase 00 C
C osed,
wall-mounting type
(conforming to IP20)
0.2 (0.25) kW 3G3JV-A2002
(conforming to IP20)
0.4 (0.55) kW 3G3JV-A2004
0.75 (1.1) kW 3G3JV-A2007
1.5 (1.5) kW 3G3JV-A2015
2.2 (2.2) kW 3G3JV-A2022
Single-phase 200 VAC Closed,
ll i
0.1 (0.1) kW 3G3JV-AB001
S g e p ase 00 C
C osed,
wall-mounting type
(conforming to IP20)
0.2 (0.25) kW 3G3JV-AB002
(conforming to IP20)
0.4 (0.55) kW 3G3JV-AB004
0.75 (1.1) kW 3G3JV-AB007
1.5 (1.5) kW 3G3JV-AB015
Note The figures in parentheses indicate capacities for motors used outside Japan.
H International Standards (EC Directives and UL/cUL
Standards)
The 3G3JV Inverter meets the EC Directives and UL/cUL standard requirements for
worldwide use.
Classification Applicable standard
EC Directives
EMC directive EN50081-2 and EN5008-2
C ect es
Low-voltage directive prEN50178
UL/cUL UL508C
Overview Chapter 1

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
