Omron SYSDRIVE 3G3JV Series User Manual

1-3
H Versatile Easy-to-use Functions
•Incorporates the functions and operability ensured by the conventional 3G3EV Series.
•Easy to initialize and operate with the FREQ adjuster on the Digital Operator.
•Ease
of maintenance. The cooling fan is easily replaceable. The life of the cooling fan
can be prolonged by turning on the cooling fan only when the Inverter is in operation.
•Optional RS232 (3G3JV -PSI232J) and RS422/485 MODBUS (3G3JV -PSI485J) inter -
face cards.
H Suppression of Harmonics
Connects to DC reactors, thus suppressing harmonics more effectively than conven-
tional AC reactors.
Further
improvement in the suppression of harmonics is possible with the combined use
of the DC and AC reactors.
Overview Chapter 1

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
