5-24
5-10 Analog Monitor Output
The 3G3JV incorporates analog monitor output terminals AM and AC.
These terminals have analog monitor values of output frequency or cur-
rent.
H Setting the Analog Monitor Output (n44 and n45)
The output frequency or current as a monitored item is set in n44.
The analog output characteristics are set as an analog monitor output gain in n45.
n44 Analog Monitor Output Changes during
operation
No
Setting
range
0, 1 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 Output frequency (Reference: 10 V at max. frequency)
1 Output current (Reference: 10 V with rated output current)
n45 Analog Monitor Output Gain Changes during
operation
Yes
Set range 0.00 to 2.00 Unit of
setting
0.01 Default setting 1.00
Note 1. Set the multiplication ratio based on the set value in n44.
For
example, if an output of 5 V is desired at maximum frequency (with n44 set
to 0), set n45 to 0.50.
Note 2. The
maximum output voltage of the analog monitor output terminals are 10 V
.
