5-23
Set Values
Value Function Description
0 Fault output ON: Fault output (with protective function working)
1 Operation in progress ON: Operation in progress (with RUN command input or
inverter output)
2 Frequency detection ON: Frequency detection (with frequency reference
coinciding with output frequency)
3 Idling ON: Idling (at less than min. output frequency)
4 Frequency detection 1 ON: Output frequency y frequency detection level (n58)
5 Frequency detection 2 ON: Output frequency x frequency detection level (n58)
6 Overtorque being
monitored
(NO-contact output)
Output if any of the following parameter conditions is
satisfied.
•Overtorque detection function selection (n59)
•Overtorque detection level (n60)
7 Overtorque being
monitored
(NC-contact output)
•
O
vertorque
d
etect
i
on
l
eve
l
(
n
60)
•Overtorque detection time (n61)
Note NO contact: ON with overtorque being detected;
NC contact: OFF with overtorque being detected
10 Alarm output ON: Alarm being detected (Nonfatal error being
detected)
11 Base block in
progress
ON: Base block in progress (in operation with output
shutoff)
12 RUN mode ON: Local mode (with the Digital Operator)
13 Inverter ready ON: Inverter ready to operate (with no fault detected)
14 Fault retry ON: Fault retry (Inverter resetting with fault retry (n48)
not set to 0)
15 UV in progress ON: Undervoltage being monitored (main circuit
undervoltage UV1 detected)
16 Rotating in reverse
direction
ON: Rotating in reverse direction
17 Speed search in
progress
ON: Speed search in progress
Basic Operation Chapter 5

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
