Omron SYSDRIVE 3G3JV Series User Manual

5-6
5-3 Setting the Local/Remote Mode
The 3G3JV operates in local or remote mode. The following description
provides information on these modes and how to select them.
H Basic Concept
Operation mode Basic concept Description
Local The Inverter in a system
operates independently in
this mode so that the
Inverter can be checked
independently.
Operation Command
Starts with the RUN Key of the Digital
Operator and stops with the
STOP/RESET Key.
Frequency Reference
Set with the Digital Operator or the FREQ
adjuster.
Set with frequency reference selection in
local mode in n07.
Remote The Inverter in a system
operates according to the
control signal of the host
controller.
Operation Command
Selectable from two types and set in n02.
Frequency Reference
Selectable from five types and set in n03.
H Local/Remote Selection Methods
•The following two selection methods are available to set the Inverter to local or remote
mode.
S Select the mode with the LO/RE Key of the Digital Operator.
S Set
any one of multi-function inputs 1 through 4 (n36 through n39) to 17 to set the
Inverter to local mode with control input turned ON.
Note If
the above setting is made, mode selection with multi-function input will be pos -
sible, but not with the Digital Operator.
Basic Operation Chapter 5

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
