5-11
5-5-4 Setting Frequency References through Key
Sequences
The following description provides information on parameters related to
frequency
reference settings through key sequences on
the Digital Opera
-
tor
H Setting Frequency References 1 through 8 and the Inching
Frequency Command (n21 through n28 and n29)
A
total of nine frequency references (frequency references 1 through 8) and an inching
frequency command can be set together in the Inverter.
D Setting Frequency References 1 through 8 (n21 through n28)
n21 Frequency Reference 1 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz
(see note 1)
Default setting 6.0
n22 Frequency Reference 2 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz
(see note 1)
Default setting 0.0
n23 Frequency Reference 3 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz
(see note 1)
Default setting 0.0
n24 Frequency Reference 4 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz
(see note 1)
Default setting 0.0
n25 Frequency Reference 5 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz
(see note 1)
Default setting 0.0
n26 Frequency Reference 6 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz
(see note 1)
Default setting 0.0
n27 Frequency Reference 7 Changes during
operation
Yes
Setting
range
0.0 to max. frequency Unit of
setting
0.01 Hz
(see note 1)
Default setting 0.0
Basic Operation Chapter
5
