Omron SYSDRIVE 3G3JV Series User Manual

!
!
!
!
!
2-4
2-1-2 Installation Conditions
Caution Be sure to install the product in the correct direction and provide spe -
cified
clearances between the Inverter and control panel or with oth -
er devices. Not doing so may result in fire or malfunction.
Caution Do not allow foreign objects to enter inside the product. Doing so
may result in fire or malfunction.
Caution Do
not apply any strong impact. Doing so may result in damage to
the product or malfunction.
Caution Provide an appropriate stopping device on the machine side to
secure
safety . (A holding brake is not a stopping device for securing
safety.) Not doing so may result in injury.
Caution Provide an external emergency stopping device that allows an
instantaneous stop of operation and power interruption. Not doing
so may result in injury.
Design Chapter 2

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
