5-3
H Setting the Rated Motor Current (n32)
Set the rated motor current (n32) in order to prevent the motor from burning due to over -
loading.
Check the rated current on the motor nameplate and set the parameter.
This
parameter is used for the electronic thermal function for motor overload detection
(OL1). By setting the correct parameter, the overloaded motor will be protected from
burning.
n32 Rated Motor Current Changes during
operation
No
Setting
range
0.0% to 120% (A) of rated
output current of Inverter
Unit of
setting
0.1 A Default setting (see
note 1)
Note 1. The standard rated current of the maximum applicable motor is the default
rated motor current.
Note 2. Motor overload detection (OL1) is disabled by setting the parameter to 0.0.
Basic Operation Chapter 5

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
