Omron SYSDRIVE 3G3JV Series User Manual

5-16
H S-shape Acceleration/Deceleration Characteristic (n20)
•Trapezoidal and S-shape acceleration and deceleration are available. Using the S-
shape characteristic function for acceleration and deceleration can reduce shock to
the machinery when stopping or starting.
•Any
one of three S-shape acceleration/deceleration times (0.2, 0.5, and 1.0 s) is se -
lectable.
n20 S-shape Acceleration/Deceleration
Characteristic
Changes during
operation
No
Setting
range
0 to 3 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 No S-shape acceleration/deceleration characteristic (Trapezoidal
acceleration/deceleration)
1 S-shape acceleration/deceleration characteristic time is 0.2 s
2 S-shape acceleration/deceleration characteristic time is 0.5 s
3 S-shape acceleration/deceleration characteristic time is 1.0 s
Note When the S-shape acceleration/deceleration characteristic time is set, the accel -
eration and deceleration times will be lengthened according to the S-shape at the
beginning and end of acceleration/deceleration.
Basic Operation Chapter 5

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
