Omron SYSDRIVE 3G3XV-EV2 Series - Description of Functions and Constants

To Next Page

To Previous Page

Third Functions (Constant Nos. 30 to 49)

Function No. Name Description Initial

setting

User

set

values

See

Page

Stall Prevention 30 Level of stall

preventive

operation

during

acceleration

Setting unit: 1%, setting range 30% to

200%

Note: Stall prevention is not performed

during acceleration when 200% is set.

170% 51

31 Level of stall

preventive

operation

during run-

ning

Setting unit: 1%, setting range 30% to

200%

Note: Stall prevention is not performed

during run when 200% is set.

160%

Multi-

func-

tion

selec-

tion

Contact

input

signal

32 Multifunction

input selec-

tion 1 (termi-

nal 4 func-

tion selec-

tion)

0: FWD/REV run command

(3-WIRE sequence selection)

1: External fault (NO contact input)

2: External fault (NC contact input)

3: Multi-step speed reference 1

4:Multi-step speed reference 2

5: JOG command

6: Accel/decel time select

7: External baseblock (NO contact input

8: External baseblock (NC contact input)

9: Speed search from max. frequency

10: Speed search from set frequency

11: Accel/decel prohibit

12: Local/Remote operation

1 53

33 Multifunction

input selec-

tion 2 (termi-

nal 5 func-
