Omron SYSDRIVE 3G3XV-EV2 Series - Page 45

42
Function See
Page
User
set
values
Initial
setting
DescriptionNameNo.
Multi-
func-
tion
selec-
tion
Photo-
coupler
output
signal
34 Multifunction
input selec-
tion 1 (termi-
nal 13 func-
tion selec-
tion)
0: Running
1: Frequency coincidence
2: Zero speed
3: Frequency detection (output frequency
≥ frequency detection level)
4: Overtorque detection
5: Operation mode
0 55
35 Multifunction
input selec-
tion 2 (termi-
nal 14 func-
tion selec-
tion)
0: Running
1: Frequency coincidence
2: Zero speed
3: Frequency detection (output frequency
≥ frequency detection level)
4: Overtorque detection
5: Operation mode
1
Desired speed
detection
36 Frequency
detection
level
Setting unit: 0.1 Hz, setting range: 0.0 to
400.0 Hz
0.0 Hz 57
Overtorque
detection
37 Overtorque
detection
function
selection
1
st
digit = 0: Overtorque detection not
provided
= 1: Overtorque detection pro-
vided
0000
1
st
digit
4
th
digit
56
2
nd
digit = 0: Detected only during
speed coincidence
= 1: Detected during running
3
rd
digit = 0: Operation continued after
overtorque detection
= 1: Output shut-off at overtor-
que detection
4
th
digit: Not used
38 Overtorque
detection
level
Setting unit: 1%, setting range: 30% to
200%
160%
39 Overtorque
detection
time
Setting unit: 0.1 s, setting range: 0.1 to
10.0 s
0.1 s
Carrier fre-
quency adjust-
ment
40 Carrier fre-
quency
Setting unit: 2.5 kHz, setting range: 1 to
6 (2.5 to 15 kHz)
4
(10 kHz)
57
––– 41
to
44
Not used. Setting disabled. ––– ––– –––
Analog monitor
scale calibra-
tion
45 Analog mon-
itor gain
Setting unit: 0.01, setting range: 0.01 to
2.00
1.00 55
Function/Constant List Section 2-7
