14 Serial Communications
14-22
CP2E CPU Unit Software User’s Manual(W614)
z Programming Example
Initial
Frequency
Setting
Frequency setting at
operation startup
Write 60.00 Hz (1770 Hex)
to register number 0002
(Hex)
D1300
MOV(021)
#1
Slave address
01 Hex
FUNCTION code
06 Hex
Communication data
4 bytes (Hex)
Frequency setting 60.00 Hz
1770 Hex
Slave address
01 Hex
FUNCTION code
05 Hex
Communication data
4 bytes (Hex)
ON
FF00 Hex
Register number 0001 Hex
(Register number -1)
0001 Hex
Register number 0002 Hex
(Register number -1)
0001 Hex
D1301
MOV(021)
#6
D1302
MOV(021)
#4
D1303
MOV(021)
#1
D1304
MOV(021)
#1770
RUN
Command
Start operation
Write ON (FF00 Hex) to coil
number 0001 (Hex)
D1300
MOV(021)
#1
D1301
MOV(021)
#5
MOV(021)
#4
D1303
MOV(021)
#0
D1304
MOV(021)
#FF00
W0.00
W1.00
D1302
