15 Ethernet
15-30
CP2E CPU Unit Software User’s Manual(W614)
IP Address Table Records (Command)
Specify the IP address table records. The number of records specified must be provided. The total
number of bytes in the IP address table records is calculated as the number of records × 6
bytes/record. The configuration of the 6 bytes of data in each record is as shown in the following dia-
gram.
• FINS Node Address
Node address for communications via the FINS command (hexadecimal).
•IP Address
IP address used by TCP/IP protocol (hexadecimal).
Precautions for Correct UsePrecautions for Correct Use
The new I/O address table records will not be effective until the PC is restarted or the Ethernet
Unit is reset.
An error response will be returned if the IP address conversion method in the system mode set-
tings is set for automatic generation.
Response Codes
z IP ROUTER TABLE WRITE: 2751
Writes the IP router table.
Command Block
Response Block
Response code Description
0000 Normal (echo reply received from the remote node)
1004 Command format error
1003 The number of records specified does not match the sent data
length.
110C The number of records is not between 0 and 32.
The FINS node address is not between 1 and 126
The IP address is 0.
2307 IP address conversion method is set for automatic generation.
FINS node
number
1
00
IP address
6 bytes
Number
of records
IP router
table records
Command
code
27 51
IP router
table records
8 bytes 8 bytes
Command
code
Response
code
27 51
