Appendices
CP2E CPU Unit Software User’s Manual(W614)
A-2 Auxiliary Area Allocations by Address
App
A-2-1 Read-only Words
A313 --- Error Contents for
Ethernet Errors
An error content is registered when a
built-in Ethernet error or Ethernet
setting table error occurs.
For details of the
error contents, refer
to 6-1-10 Non-fatal
Errors in the CP2E
CPU Unit Hardware
User's Manual (Cat.
No. W613).
Cleared Cleared Refreshed
when a
non-fatal error
occurs.
A315.10
A315 10 Built-in Etherent
Contents/Setup Error
Flag
ON when an error occurs in the
connection/setting of FINS/TCP, SNTP
and DNS server.
ON: Error
OFF: Normal
Cleared Cleared Refreshed
when a
non-fatal error
occurs.
A313
A402.00
11 Logic Error in Setting
Tables
ON when an error occurs in the routing
table, IP address table and IP router
table.
The error code is stored in A313.
ON: Error
OFF: Normal
Cleared Cleared Refreshed
when a
non-fatal error
occurs.
A402.00
13 Option Board Error
Flag
ON when the Option Board is removed
while the power is being supplied.
ON when two Analog Option Boards
are mounted.
CPU Unit operation will continue and
the ERR/ALM indicator will flash.
Note OFF when the error has been
cleared.
ON: Error
OFF: Normal
Cleared Cleared Refreshed
when a
non-fatal error
occurs.
A402.00,
A424
15 Backup Memory Error
Flag
ON when writing to the built-in Flash
Memory fails. CPU Unit operation will
continue and the ERR/ALM indicator
will flash.
Note OFF when the error has been
cleared.
ON: Error
OFF: Normal
Cleared Cleared Refreshed
when a
non-fatal error
occurs.
A402.00
A316
to A317
--- High-speed Counter 2
PV
Cont
ain
s the PV of high-speed counter
2.
A317 contains the upper 4 digits and
A316 contains the lower 4 digits.
Cleared Cleared • Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read PV.
• Refreshed
when INI
instruction is
executed.
A318 to
A319
--- High-speed Counter 3
PV
Contains the PV of high-speed counter
3.
A319 contains the upper 4 digits and
A318 contains the lower 4 digits.
Cleared Cleared • Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read PV.
• Refreshed
when INI
instruction is
executed.
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
