A320 00 High-speed Counter 2
Range 1 Comparison
Condition Met Flag
These flags indicate whether the PV is
within the specified ranges when
high-speed counter 2 is being operated
in range-comparison mode for upper
and lower limits.
ON: PV in range
OFF: PV not in range
Cleared Cleared • Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read the
results of
range com-
parison.
• Refreshed
when range
comparison
table is reg-
istered.
01 High-speed Counter 2
Range 2 Comparison
Condition Met Flag
02 High-speed Counter 2
Range 3 Comparison
Condition Met Flag
03 High-speed Counter 2
Range 4 Comparison
Condition Met Flag
04 High-speed Counter 2
Range 5 Comparison
Condition Met Flag
05 High-speed Counter 2
Range 6 Comparison
Condition Met Flag
08 High-speed Counter 2
Comparison
In-progress Flag
This flag indicates whether a
comparison operation is being
executed for high-speed counter 2.
ON: Being executed
OFF: Stopped
--- Cleared Refreshed
when
comparison
operation
starts or stops.
09 High-speed Counter 2
Overflow/Underflow
Flag
This flag indicates when an overflow or
underflow has occurred in the
high-speed counter 2 PV. (Used with
the linear mode counting range only.)
ON: Overflow or
underflow
OFF: Normal
Cleared Cleared • Refreshed
when an
overflow or
underflow
occurs.
• Refreshed
when PV is
changed.
10 High-speed Counter 2
Count Direction
This flag indicates whether the
high-speed counter 2 is currently being
incremented or decremented. The
counter PV for the current cycle is
compared with the PV in last cycle to
determine the direction.
ON: Incrementing
OFF: Decrementing
--- Cleared Setting used
for high-speed
counter, valid
during counter
operation.
A321 00 High-speed Counter 3
Range 1 Comparison
Condition Met Flag
These flags indicate whether the PV is
within the specified ranges when
high-speed counter 3 is being operated
in range-comparison mode for upper
and lower limits.
ON: PV in range
OFF: PV not in range
Cleared Cleared • Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read the
results of
range com-
parison.
• Refreshed
when range
comparison
table is reg-
istered.
01 High-speed Counter 3
Range 2 Comparison
Condition Met Flag
02 High-speed Counter 3
Range 3 Comparison
Condition Met Flag
03 High-speed Counter 3
Range 4 Compa
rison
Condit
ion Met Flag
04 High-speed Counter 3
Range 5 Comparison
Condition Met Flag
05 High-speed Counter 3
Range 6 Comparison
Condition Met Flag
08 High-speed Counter 3
Comparison
In-progress Flag
This flag indicates whether a
comparison operation is being
executed for high-speed counter 3.
ON: Being executed
OFF: Stopped
--- Cleared Refreshed
when
comparison
operation
starts or stops.
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
