A-73
Appendices
CP2E CPU Unit Software User’s Manual(W614)
A-2 Auxiliary Area Allocations by Address
App
A-2-1 Read-only Words
A321 09 High-speed Counter 3
Overflow/Underflow
Flag
This flag indicates when an overflow or
underflow has occurred in the
high-speed counter 3 PV. (Used with
the linear mode counting range only.)
ON: Overflow or
underflow
OFF: Normal
Cleared Cleared • Refreshed
when an
overflow or
underflow
occurs.
• Refreshed
when PV is
changed.
10 High-speed Counter 3
Count Direction
This flag indicates whether the
high-speed counter is currently being
incremented or decremented. The
counter PV for the current cycle is
compared with the PV in last cycle to
determine the direction.
ON: Incrementing
OFF: Decrementing
--- Cleared Setting used
for high-speed
counter, valid
during counter
operation.
A322
to A323
High-speed Counter 4
PV
Contains the PV of high-speed counter
4.
A323 contains the upper four digits and
A322 contains the lower four digits.
Cleared Cleared • Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read PV.
• Refreshed
when INI
instruction is
executed.
A324 to
A325
High-speed Counter 5
PV
Contains the PV of high-speed counter
5.
A325 contains the upper 4 digits and
A324 contains the lower 4 digits.
Cleared Cleared • Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read PV.
• Refreshed
when INI
instruction is
executed.
A326 00 High-speed Counter 4
Range 1 Comparison
Condition Met Flag
These flags indicate whether the PV is
within the specified ranges when
high-speed counter 4 is being operated
in range-comparison mode for upper
and lower limits.
ON: PV in range
OFF: PV not in range
Cleared Cleared • Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
w
h
en PRV
instruction is
executed to
read the
results of
range com-
parison.
• Refreshed
when range
comparison
table is reg-
istered.
01 High-speed Counter 4
Range 2 Comparison
Condition Met Flag
02 High-speed Counter 4
Range 3 Comparison
Condition Met Flag
03 High-speed Counter 4
Range 4 Comparison
Condition Met Flag
04 High-speed Counter 4
Range 5 Comparison
Condition Met Flag
05 High-speed Counter 4
Range 6 Comparison
Condition Met Flag
08 High-speed Counter 4
Comparison
In-progress Flag
This flag indicates whether a
comparison operation is being
executed for high-speed counter 4.
ON: Being executed
OFF: Stopped
--- Cleared Refreshed
when
comparison
operation
starts or stops.
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
