Omron SYSMAC CPM1 User Manual

6-5SectionI/O Wiring
104
6-1 Specifications
Item Specifications
Number of analog
outputs
1
Output signal range
Voltage output 0 V to +10 V
–10 V to +10 V
Current output 4 mA to 20 mA
Resolution
Voltage output 0 to 10 V: 1/256
–10 to 10 V: 1/512
Current output 1/256
Accuracy
Voltage output 1.0% max. (full scale)
Current output 1.0% max. (full scale)
Number of analog
inputs
2
Input signal range
Voltage input 0 V to +10 V
1 V to +5 V
Current input 4 mA to 20 mA
Resolution
Voltage input 1/256
Current input 1/256
Accuracy
Voltage input 1.0% max. (full scale)
Current input 1.0% max. (full scale)
Conversion time
(See note.)
10 ms. max./ Unit
Maximum output
current
Voltage output 5 mA
Maximum load
resistance
Current output 500 Ω
Maximum total output
current for Unit
21 mA
Maximum input signal
Voltage input ±15 V
Current input ±30 mA
PC signal
Voltage output 8-bit binary + sign bit
(80FF to 0000, 0000 to 00FF
hexadecimal)
Current output 8-bit binary
(0000 to 00FF hexadecimal)
External connections 9-pin terminal block (non-removable)
Insulation Between output/input terminals and PC: Photocouplers
Between output terminals individual: None
Power consumption At 5 VDC: 60 mA max.
At 24 VDC: 60 mA max.
Supplied from CPU Unit.
Dimensions 66 50 90 mm (W x H x D)
Weight 150 g max.
Note The conversion time is for a complete refresh of inputs and outputs for the Unit.
• Voltage and current outputs can be used at the same time as long as the total
output current is 21 mA or less.
• Data written to the output word is valid for both the current and voltage outputs.
• Data read from the input words is valid for the current or voltage input.
