76
tents of the specified word are converted automatically to signed hexadeci-
mal (two’s complement format).
Words SR 253 to SR 255 cannot be changed.
RUN MONITOR PROGRAM
No OK OK
Caution Check that there is no effect on equipment before changing the current values.
1, 2, 3... 1. Monitor (signed decimal) the status of the word for which the present value
is to be changed.
(Signed decimal monitor)
c000
Ć00016
2. Press the CHG Key to begin decimal data modification.
CHG
PRES VAL?
c000 Ć00016
3. Input the new PV and press the WRITE Key to change the PV. The operation
will end and the signed-decimal monitoring display will return when the
WRITE Key is pressed.
The PV can be set within a range of –32,768 and 32,767. Use the SET Key to
input a positive number, and use the RESET Key to input a negative number.
REC
RESET
D
3
C
2 7 6 8
WRITE
c000
Ć32768
Press the CLR Key or the SHIFT and TR Keys to return to the normal moni-
toring display.
If an erroneous input has been made, press the CLR Key to restore the sta-
tus prior to the input. Then enter the correct input.
4-3-22 Unsigned Decimal Data Modification
This operation is used to change the decimal value of a word being moni-
tored as unsigned decimal data, within a range of 0 to 65,535. A change into
hexadecimal data is made automatically.
Words SR 253 to SR 255 cannot be changed.
RUN MONITOR PROGRAM
No OK OK
Caution Check that there is no effect on equipment before changing the current values.
1, 2, 3... 1. Monitor (unsigned decimal) the status of the word for which the present
value is to be changed.
(Unsigned decimal monitor)
c000
65520
2. Press the CHG Key to begin decimal data modification.
CHG
PRES VAL?
c000 65520
3. Input the new PV and press the WRITE Key to change the PV. The operation
will end and the decimal-without-sign monitoring display will return when the
WRITE Key is pressed.
The PV can be set within a range of 0 to 65,535.
D
3
C
2 7 6 8
WRITE
c000
32768
Programming Console Operations
Section 4-3
