1, 2, 3... 1. Set the Programming Console’s mode switch to PROGRAM mode and turn
on the CPM1’s power supply. The password input display will appear on the
Programming Console.
RUN
MONITOR
PROGRAM
<PROGRAM>
PASSWORD!
2. Enter the password by pressing the CLR and then the MONTR Key.
CLR MONTR
<PROGRAM>
At this point, the SHIFT and then the 1 key can be pressed to turn on and off
the Programming Console’s buzzer. Refer to page 61.
3. Clear the CPM1’s memory by pressing the CLR, SET, NOT, RESET, and
then the MONTR Key. Press the CLR Key several times if memory errors are
displayed.
CLR
00000
SET
NOT
RESET
00000MEMORY CLR?
HR CNT DM
MONTR
00000MEMORY CLR
END HR CNT DM
4. Display and clear error messages by pressing the CLR, FUN, and then the
MONTR Key. Continue pressing the MONTR Key until all error messages
have been cleared.
CLR
00000
FUN
00000
FUN(0??)
MONTR
00000ERR CHK
OK
5. Press the CLR Key to bring up the initial programming display (program
address 00000). The new program can be written at this point.
CLR
00000
Caution Be sure that the mode selector is set to PROGRAM before entering the pass-
word. Check the system thoroughly before executing the CPM1 program to pre-
vent any accidents that might occur when the program is first started.
