Omron VARISPEED L7 User Manual

XII
Line Filters
Recommended Line Filters for Varispeed L7
Maximum Voltage: AC 480V 3phase
Ambient Temperature: 45°C (max.)
*Permissible emission of power drive systems for commercial and light environment (EN61800-3, A11)
(general availability, 1st environment)
Maximum Voltage: AC 240V 3phase
Ambient Temperature: 45°C (max.)
* max. motor cable length: 10 m Class B, 50 m Class A
Rated Voltage: AC240V 3 ph.
Ambient Temperature: 45°C (max.)
Inverter Model Line Filter
Varispeed L7 Model
Current
(A)
Weight
(kg)
Dimensions
W x D x H
CIMR-L7Z43P77
3G3RV-PFI3018-SE 18 1.3 141 x 46 x 330CIMR-L7Z44P07
CIMR-L7Z45P57
CIMR-L7Z47P57
3G3RV-PFI3035-SE 35 2.1 206 x 50 x 355
CIMR-L7Z40117
CIMR-L7Z40157
3G3RV-PFI3060-SE 60 4.0 236 x 65 x 408
CIMR-L7Z40187
CIMR-L7Z40227
3G3RV-PFI3070-SE 70 3.4 80 x 185 x 329
CIMR-L7Z40307
CIMR-L7Z40377
3G3RV-PFI3130-SE 130 4.7 90 x 180 x 366CIMR-L7Z40457
CIMR-L7Z40557
Inverter Model Line Filter
Varispeed L7 Model
Current
(A)
Weight
(kg)
Dimensions
W x D x H
CIMR-L7Z23P77
3G3RV-PFI2035-SE 35 1.4 141 x 46 x 330
CIMR-L7Z25P57
CIMR-L7Z27P57 3G3RV-PFI2060-SE 60 3.0 206 x 60 x 355
CIMR-L7Z20117
CIMR-L7Z20157 3G3RV-PFI2100-SE 100 4.9 236 x 80 x 408
CIMR-L7Z20187
CIMR-L7Z20227 3G3RV-PFI2130-SE 130 4.3 90 x 180 x 366
CIMR-L7Z20307
CIMR-L7Z20377 3G3RV-PFI2160-SE 160 6.0 120 x 170 x 451
CIMR-L7Z20457 3G3RV-PFI2200-SE 200 11.0 130 x 240 x 610
CIMR-L7Z20557
